Positioning of 2810 motor
Compared to the same-size BLDC S2807, the iron core thickness has increased from 7mm to 10mm, providing a larger effective area of magnetic steel and significantly enhancing low-speed torque. Designed as the main all-round motor for 8-inch heavy-duty long-range drones, it bridges the gap between the 2807 (pure long-range) and 2812 (high payload) models.
Optimized structure,enhanced efficiency
Adopting a 12N14P high-efficiency slot-pole structure + low-resistance winding, it minimizes power loss; with a 10%+ efficiency improvement over standard 2810 motors, it delivers longer endurance on the same battery, maintains stable hovering without power drop, and is ideal for long-distance inspections and aerial photography.
Top-tier materials, durable and reliable
Equipped with N52H high-temperature-resistant neodymium iron boron magnets and Class H high-temperature-resistant insulation windings, it is resistant to heating, demagnetization, and burnout even during continuous high-power operation, significantly enhancing durability compared to ordinary 2810 motors, making it suitable for industrial-grade prolonged operation. Moreover, the entire unit weighs only 62g, maintaining lightweight while enhancing power with a thickened iron core.
Highly compatible
The 2810 motor features a standard mounting hole spacing of 16×19mm, compatible with all 28-series frames on the market, allowing direct replacement of 2807 and 2812 motors. It supports a wide voltage input of 4–6S, pairs with mainstream 50–60A ESCs, and offers straightforward upgrade replacement.
Motor specifications and parameters
|
Basic electrical parameters |
Size specifications |
Recommended configuration |
|||
|
KV Rating |
1150KV (customizable：900/1300KV) |
stator dimensions |
28mm × 10mm |
drone |
APEX HD 7-inch,Mark4 V2 8-inch,7‑8-inch FPV |
|
Slot‑Pole Configuration |
12N14P |
rotor outer diameter |
35mm |
propeller |
7-inch / 8-inch FPV propeller |
|
Internal resistance |
≤42mΩ |
Spindle diameter |
5mm |
ESC |
50A–60A FPV Brushless ESC |
|
Input Voltage |
4S‑6S LiPo |
Weight |
62g ±1g |
Max Thrust |
3.2–3.5kg |
|
rated current |
28A |
Motor Mount Hole |
16×19mm |
Dynamic Balance |
≤5mg |
|
Peak current |
60A |
Wire Outlet Type |
Side Exit |
working temperature |
‑20℃～+120℃ |
For more performance parameters, please contact us for customization
Customer Reviews
To produce a knife with perfect precision to perform, high-tech machines in all steps of raw material processing are vital.
- Russian・Игорь Смирнов
- USA・Dylan Peterson
- Japan・はやしだ じゅん
- Germany・Leon Müller
- Australia・Noel Carter
-
Russian・Игорь СмирновWe purchased 2810 motors in batches for patrol drones. It works steadily in low temperature and windy weather, with stable power output and few operational faults.
-
USA・Dylan PetersonMass procurement test shows qualified overall quality. The motor has fine heat dissipation and durable performance, ideal for assembling medium-sized FPV and inspection drones.
-
Japan・はやしだ じゅんLow vibration and smooth operation. It perfectly fits aerial survey equipment assembly, and batch products maintain stable consistent quality.
-
Germany・Leon MüllerPrecise response and low heat generation. The motor maintains consistent performance during long-hour continuous operational tasks.
-
Australia・Noel CarterGreat endurance and wind resistance. The motors fully satisfy long-distance field patrol and outdoor exploration flight demands.
Company Profile
Upholding the philosophy of sustainable innovation and continuous iteration, Xpert Intelligent Equipment Co., Ltd. has focused on drone and accessory R&D and manufacturing for 11 consecutive years. Relying on two dedicated R&D centers, we continuously optimize product appearance and structural design, upgrade core flight performance, and enrich diversified product categories. Cooperated with standardized production workshops and professional testing bases, we guarantee stable and excellent quality for every product batch. Persistent technological and quality upgrading helps our products maintain stable market share in global mainstream regions.
Factory Strength
Xper has six exclusive production facilities for drones and accessories, covering an area of 24,000㎡, equipped with over 330 internationally advanced intelligent production devices, and has established an integrated mature production system. From precision processing of raw materials to R&D and manufacturing of core components, and all the way to final assembly and testing, the entire process is independently completed. Moreover, standardized production processes have been established, and backed by robust manufacturing expertise, the company firmly ranks among the industry's top tier, enabling efficient handling of various batch orders.
FAQ
1. What are the advantages compared to the BLDC S2807?
The iron core is thickened to 10mm, increasing low-speed torque by 25%+; the 12N14P high-efficiency slot-pole + low-resistance winding delivers stronger power and longer range, balancing long-distance travel with light load capacity-positioned as an all-round performer.
2. Which drones can it be used on?
7-8 inch heavy-duty long-range FPV drones, high-definition aerial photography drones, small power inspection drones, surveying and mapping drones, light-duty logistics delivery drones.
3. Is it interchangeable with the 2812 motor?
The mounting holes are compatible, allowing direct interchangeability. The 2810 model focuses on balanced endurance + light load capacity, while the 2812 emphasizes greater load capacity and thrust.
4. Structural stability?
Reinforced rotor design, shock-resistant structure, strong crash resistance for outdoor flight.
5. Core performance advantages?
High energy efficiency, low static current, greatly improve flight duration for long-distance mission.
